# Copyright:Public domain.
# Filename:AGC_BLOCK_TWO_SELF-CHECK.agc
# Purpose:Part of the source code for Colossus 2A, AKA Comanche 055.
#It is part of the source code for the Command Module's (CM)
#Apollo Guidance Computer (AGC), for Apollo 11.
# Assembler:yaYUL
# Contact:Ron Burkey <info@sandroid.org>.
# Website:www.ibiblio.org/apollo.
# Pages:1394-1403
# Mod history: 2009-05-10 SN (Sergio Navarro). Started adapting
#from the Colossus249/ file of the same
#name, using Comanche055 page images.
#
# This source code has been transcribed or otherwise adapted from digitized
# images of a hardcopy from the MIT Museum. The digitization was performed
# by Paul Fjeld, and arranged for by Deborah Douglas of the Museum. Many
# thanks to both. The images (with suitable reduction in storage size and
# consequent reduction in image quality as well) are available online at
# www.ibiblio.org/apollo. If for some reason you find that the images are
# illegible, contact me at info@sandroid.org about getting access to the
# (much) higher-quality images which Paul actually created.
#
# Notations on the hardcopy document read, in part:
#
# Assemble revision 055 of AGC program Comanche by NASA
# 2021113-051. 10:28 APR. 1, 1969
#
# This AGC program shall also be referred to as
# Colossus 2A

# Page 1394
# PROGRAM DESCRIPTIONDATE 20 DECEMBER 1967
# PROGRAM NAME - SELF-CHECKLOG SECTION AGC BLOCK TWO SELF-CHECK
# MOD NO - 1ASSEMBLY SUBROUTINE UTILITYM REV 25
# MOD BY - GAUNTT
#
#
# FUNCTIONAL DESCRIPTION
#
# PROGRAM HAS TWO MAIN PARTS. THE FIRST IS SELF-CHECK WHICH RUNS AS A ZERO PRIORITY JOB WITH NO CORE SET, AS
# PART OF THE BACK-UP IDLE LOOP. THE SECOND IS SHOW-BANKSUM WHICH RUNS AS A REGULAR EXECUTIVE JOB WITH ITS OWN
# STARTING VERB.
# THE PURPOSE OF SELF-CHECK IS TO CHECK OUT VARIOUS PARTS OF THE COMPUTER AS OUTLINED BELOW IN THE OPTIONS.
# THE PURPOSE OF SHOW-BANKSUM IS TO DISPLAY THE SUM OF EACH BANK , ONE AT A TIME.
# IN ALL THERE ARE 7 POSSIBLE OPTIONS IN THIS BLOCK II VERSION OF SELF-CHECK. MORE DETAIL DESCRIPTION MAY BE
# FOUND IN E-2065 BLOCK II AGC SELF-CHECK AND SHOW BANKSUM BY EDWIN D. SMALLY DECEMBER 1966, AND ADDENDA 2 AND 3.
# THE DIFFERENT OPTIONS ARE CONTROLLED BY PUTTING DIFFERENT NUMBERS IN THE SMODE REGISTER (NOUN 27). BELOW IS
# A DESCRIPTION OF WHAT PARTS OF THE COMPUTER THAT ARE CHECKED BY THE OPTIONS, AND THE CORRESPONDING NUMBER, IN
# OCTAL, TO LOAD INTO SMODE.
# +-4ERASABLE MEMORY
# +-5FIXED MEMORY
# +-1,2,3,6,7,10 EVERYTHING IN OPTIONS 4 AND 5.
# -0SAME AS +-10 UNTIL AN ERROR IS DETECTED.
# +0NO CHECK, PUTS COMPUTER INTO THE BACKUP IDLE LOOP.
#
#
# WARNINGS
# USE OF E MEMORY RESERVED FOR SELF-CHECK (EVEN IN IDLE LOOP) AS TEMP STORAGE BY OTHER PROGRAMS IS DANGEROUS.
# SMODE SET GREATER THAN OCT 10 PUTS COMPUTER INTO BACKUP IDLE LOOP.
#
#
# CALLING SEQUENCE
#
# TO CALL SELF-CHECK KEY IN
# V 21 N 27 E OPTION NUMBER E
# TO CALL SHOW-BANKSUM KEY IN
# V 91 E DISPLAYS FIRST BANK
# V 33 E PROCEED, DISPLAYS NEXT BANK
#
#
# EXIT MODES, NORMAL AND ALARM
#
# SELF-CHECK NORMALLY CONTINUES INDEFINITELY UNLESS THERE IS AN ERROR DETECTED. IF SO + OPTION NUMBERS PUT
# COMPUTER INTO BACKUP IDLE LOOP, - OPTION NUMBERS RESTART THE OPTION.
# THE -0 OPTION PROCEEDS FROM THE LINE FOLLOWING THE LINE WHERE THE ERROR WAS DETECTED.
# SHOW-BANKSUM PROCEEDS UNTIL A TERMINATE IS KEYED IN (V 34 E). THE COMPUTER IS PUT INTO THE BACKUP IDLE LOOP
#
#
#
# OUTPUT
# Page 1395
# SELF-CHECK UPON DETECTING AN ERROR LOADS THE SELF-CHECK ALARM CONSTANT (01102) INTO THE FAILREG SET AND
# TURNS ON THE ALARM LIGHT. THE OPERATOR MAY THEN DISPLAY THE THREE FAILREGS BY KEYING IN V 05 N 09 E. FOR FURTHER
# INFORMATION HE MAY KEY IN V 05 N 08 E, THE DSKY DISPLAY IN R1 WILL BE ADDRESS+1 OF WHERE THE ERROR WAS DETECTED,
# IN R2 THE BBCON OF SELF-CHECK, AND IN R3 THE TOTAL NUMBER OF ERRORS DETECTED BY SELF-CHECK SINCE THE LAST MAN
# INITIATED FRESH START (SLAP1).
# SHOW-BANKSUM STARTING WITH BANK 0 DISPLAYS IN R1 THE BANK SUM (A +-NUMBER EQUAL TO THE BANK NUMBER), IN R2
# THE BANK NUMBER, AND IN R3 THE BUGGER WORD.
#
#
# ERASABLE INITIALIZATION REQUIRED
# ACCOMPLISHED BY FRESH START
# SMODE SET TO +0
#
# DEBRIS
# ALL EXITS FROM THE CHECK OF ERASABLE (ERASCHK) RESTORE ORIGINAL CONTENTS TO REGISTERS UNDER CHECK.
# EXCEPTION IS A RESTART. RESTART THAT OCCURS DURING ERASCHK RESTORES ERASABLE, UNLESS THERE IS EVIDENCE TO DOUBT
# E MEMORY, IN WHICH CASE PROGRAM THEN DOES A FRESH START (DOFSTART).

BANK25
SETLOCSELFCHEC
BANK

COUNT43/SELF

SBIT1EQUALSBIT1
SBIT2EQUALSBIT2
SBIT3EQUALSBIT3
SBIT4EQUALSBIT4
SBIT5EQUALSBIT5
